01
04
Key Features
- Diesel Engine
- 50 Hz
- Water / Radiator Cooled
- Silent Canopy Option
- AMF Ready
- Auto Start / Stop
- Industrial Duty
- Skid / Canopy Mounted
Genset Ratings
| Rating | kVA | kW |
|---|---|---|
| Standby | ||
| Prime |
Engine Specifications
| Property | Value |
|---|---|
| Brand | Perkins |
| Model | 2506A-E15TAG3 |
| Cylinders | 6 in-line |
| Displacement | 15.2 L |
| Aspiration | Turbocharged & aftercooled |
| Governor | Electronic |
Alternator Specifications
| Property | Value |
|---|---|
| Brand | Stamford / Leroy Somer |
| Insulation Class | H |
| Protection | IP23 |
| Voltage Regulation | ±1% |
Dimensions & Weight
| Dimension | Value |
|---|---|
| Length | 4200 mm |
| Width | 1600 mm |
| Height | 2200 mm |
| Dry Weight | 4200 kg |
| Fuel Tank Capacity | 500 L |
Safety Protection & Alarms
- Low oil pressure shutdown
- High coolant temperature alarm
- Over-speed protection
- Low fuel level warning
- Emergency stop button
- Fail to start alarm
Optional Equipment
- AMF / ATS control panel
- Remote monitoring (GSM / Ethernet)
- Fuel day tank (8–24 hours autonomy)
- Parallel operation module
- Containerized soundproof enclosure
- Jacket water heater
